Heratherm™ Advanced Protocol Ovens

Heratherm™ Advanced Protocol Ovens

Výrobca: Thermo Elect.LED GmbH (Kendro)

As well as incorporating all the benefits of Thermo Scientific™ Heratherm™ General Protocol ovens, the Heratherm™ Advanced Protocol range boasts additional features providing even more flexibility, accuracy and dependability.

  • Sophisticated timer extends the automation options available to the user: turn on or off after a pre-set time, choose between a recurring weekly timer or run oven based on the 24 hour clock
  • Highest level of temperature uniformity
  • Exceptionally low energy consumption - 60 litre models just need 170W (gravity convection) and 275W (mechanical convection) per hour to maintain 150°C
  • Adjustable fan speed for application related airflow
  • Programmable controller for temperature ramps and dwells (store up to 10 programs with 10 discrete steps, features electronically controlled fan speed and damper position)
  • Access port allows the introduction of sensors for independent data monitoring
  • A simple calibration routine ensures temperature accuracy over time
  • Boost function enables rapid heating up - no need to run the oven 24/7 (tabletop models only)
  • Optional stainless steel exterior

The number of shelves included in the scope of delivery is listed in the table.

Obj. číslo 4.009 212 9.534 164 9.534 157 4.009 218 4.009 216 9.534 158 9.534 162 4.009 223 4.009 217 4.009 214 4.009 219 4.009 222 4.009 215 4.009 220 4.009 213 4.009 221 9.534 163 9.534 165
Article Packing Unit 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1
Depth mm 565 770 565 565 770 770 738 738 738 565 565 565 738 565 565 770 770
Depth of the interior mm 389 545 343 389 545 545 518 564 564 343 343 389 518 389 343 545 545
Depth of the interior mm 480 1335 508 580 1335 1335 708 680 680 608 608 480 708 580 508 1335 1335
External dimensions (W x D x H) mm 530 x 565 x 720 1261 x 770 x 1545 778 x 770 x 1545 530 x 565 x 720 640 x 565 x 820 778 x 770 x 1545 1261 x 770 x 1545 640 x 738 x 920 640 x 738 x 920 640 x 738 x 920 640 x 565 x 820 640 x 565 x 820 530 x 565 x 720 640 x 738 x 920 640 x 565 x 820 530 x 565 x 720 1261 x 770 x 1545 1261 x 770 x 1545
Height mm 720 1545 720 820 1545 1545 920 920 920 820 820 720 920 820 720 1545 1545
Included grids 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2 2
Internal dimensions (W x D x H) mm 328 x 389 x 480 1004 x 545 x 1335 544 x 545 x 1335 354 x 343 x 508 438 x 389 x 580 544 x 545 x 1335 1004 x 545 x 1335 464 x 518 x 708 438 x 564 x 680 438 x 564 x 680 464 x 343 x 608 464 x 343 x 608 328 x 389 x 480 464 x 518 x 708 438 x 389 x 580 354 x 343 x 508 1004 x 545 x 1335 1004 x 545 x 1335
Max. grids 13 39 13 16 39 39 19 19 19 16 16 13 19 16 13 39 39
Max. operating temperature °C 330 330 330 330 330 330 330 330 330 330 330 330 330 330 330 330 330
Min. operating temperature RT + °C -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10 -10
Natural convection Yes No No No Yes No No No Yes Yes No No Yes No Yes No No No
Nominal capacity l 61 396 62 99 396 731 170 168 168 97 97 61 170 99 62 731 731
Plug type EU EU EU EU EU EU EU EU EU EU EU EU EU EU EU EU EU EU
Programmable Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Rated capacity kW 1.80 3.00 1.40 3.10 3.00 3.00 3.06 3.10 3.10 3.06 3.06 1.80 3.06 3.10 1.40 3.00 5.75
Sales Packing Unit 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00 1.00
Temp. range °C Convection Gravity Advanced Protocol,230VAC 3/PE;50/60HZ Convection Mechanical Convection Mechanical Convection Gravity Convection Mechanical Convection Mechanical Convection Mechanical Convection Gravity Convection Gravity Convection Mechanical Convection Mechanical Convection Gravity Convection Mechanical Convection Gravity Convection Mechanical Convection Mechanical Convection Mechanical
Timer is available Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes Yes
Type of auxiliary energy 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz 230 V/50 Hz
Ventilation present No Yes Yes Yes No Yes Yes Yes No No Yes Yes No Yes No Yes Yes Yes
Weight kg 44 136 44 55 136 182 69 69 69 55 55 44 69 55 44 182 182
Width mm 530 778 530 640 778 1261 640 640 640 640 640 530 640 640 530 1261 1261
Width of the interior mm 328 544 354 438 544 1004 464 438 438 464 464 328 464 438 354 1004 1004
  Obj. číslo Názov Kusov v balení Dostupnosť
4.009 212 Heratherm™ Advanced Protocol Ovens | Type : OGH60 1 x 1 Na vyžiadanie
9.534 164 Heratherm Oven OMH750 750 Ltr., mechanical convection, 230 V 3/PE, 50/60 Hz 1 Na vyžiadanie
9.534 157 Heratherm™ Advanced Protocol Ovens | Type : OMH400 1 x 1 Na vyžiadanie
4.009 218 Heratherm™ Advanced Protocol Ovens | Type : OMH60 1 x 1 Na vyžiadanie
4.009 216 Heratherm™ Advanced Protocol Ovens | Type : OGH100 SS* 1 x 1 Na vyžiadanie
9.534 158 Heratherm™ Advanced Protocol Ovens | Type : OMH400 SS 1 x 1 Na vyžiadanie
9.534 162 Heratherm™ Advanced Protocol Ovens | Type : OMH750 1 x 1 Na vyžiadanie
4.009 223 Heratherm™ Advanced Protocol Ovens | Type : OMH180 SS* 1 x 1 Na vyžiadanie
4.009 217 Heratherm™ Advanced Protocol Ovens | Type : OGH180 SS* 1 x 1 Na vyžiadanie
4.009 214 Heratherm™ Advanced Protocol Ovens | Type : OGH180 1 x 1 Na vyžiadanie
4.009 219 Heratherm™ Advanced Protocol Ovens | Type : OMH100 1 x 1 Na vyžiadanie
4.009 222 Heratherm™ Advanced Protocol Ovens | Type : OMH100 SS* 1 x 1 Na vyžiadanie
4.009 215 Heratherm™ Advanced Protocol Ovens | Type : OGH60 SS* 1 x 1 Na vyžiadanie
4.009 220 Heratherm™ Advanced Protocol Ovens | Type : OMH180 1 x 1 Na vyžiadanie
4.009 213 Heratherm™ Advanced Protocol Ovens | Type : OGH100 1 x 1 Na vyžiadanie
4.009 221 Heratherm™ Advanced Protocol Ovens | Type : OMH60 SS* 1 x 1 Na vyžiadanie
9.534 163 Heratherm™ Advanced Protocol Ovens | Type : OMH750 SS 1 x 1 Na vyžiadanie
9.534 165 Heratherm™ Advanced Protocol Ovens | Type : OMH750-3P 1 x 1 Na vyžiadanie
